Tablet Press Machine
Touch Screen Rotary Tablet Press Equipment
Touch Screen Rotary Tablet Press Equipment Performance of Tablet Compression Machine This machine is a new generation product by our factory, and this machine is a single Roller continuous automatic tablet press for pressing various kinds of different shape tablets and plain tablets It is mainly used in pharmaceutical industry and also the chemical, food, electronic industries. Product Parameters of Tablet Compression Machine TYPE SED-198-8Y-D SED-198-10Y-D SED-198-18Y-D Dies 8 10 18 Max.pressure(kn) 80 80 60 Max.Dia.of Tablet(mm) 22 22 16 Max.Depth of Fill(mm) 17 1
| Place of Origin: | China |
|---|---|
| Brand Name: | SED Pharma |
| Certification: | CE |
| Model Number: | SED-198-8Y-D |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 30 Days after receiving the deposit |
| Payment Terms: | T/T,L/C, ,Cash |
| Supply Ability: | 30 Sets Per Month |
Configuration and product details
Technical overview- Name
- Touch Screen Rotary Tablet Press Equipment
- Dies
- 8
- Max.Main Pressure
- 80KN
- Motor(kw)
- 2.2
- Max.Diameter of Tablet
- 22mm
- Max.Thickness of Tablet
- 6mm
- Turret Speed
- 5-30rpm
- Production Capacity
- 14400 Tablets Per Hour
- material
- stainless steel
- key word
- Tablet Press Machine
Touch Screen Rotary Tablet Press Equipment
Performance of Tablet Compression Machine
This machine is a new generation product by our factory, and this machine is a single Roller continuous automatic tablet press for pressing various kinds of different shape tablets and plain tablets It is mainly used in pharmaceutical industry and also the chemical, food, electronic industries.
Product Parameters of Tablet Compression Machine
| TYPE | SED-198-8Y-D | SED-198-10Y-D | SED-198-18Y-D |
| Dies | 8 | 10 | 18 |
| Max.pressure(kn) | 80 | 80 | 60 |
| Max.Dia.of Tablet(mm) | 22 | 22 | 16 |
| Max.Depth of Fill(mm) | 17 | 17 | 17 |
| Max.Thickness of Tablet(mm) | 6 | 6 | 6 |
| Turret Speed(r/min) | 5-30 | 5-30 | 5-30 |
| Production Capacity(pc/h) | 14400 | 18000 | 32000 |
| Motor(kw) | 2.2 | 2.2 | 2.2 |
| Overall Size(mm) | 750×660×1620cm | ||
| Net Weight(kg) | 780KG |
||
Main Features of Tablet Compression Machine
1. Design of GMP.
2. High quality all stainless steel constructions.
3. Reliable safety sealing system and dust-proof system.
4. High visibility isolated door to prevent cross contamination.
5. Easily remove parts for quick machine’s maintenance.
Application of Tablet Compression Machine
This type of rotary tablet press is mainly used in pharmaceutical, food, chemical, electronic
and other industries. This machine is used to compress all kinds of powder and granular materials that meet the requirements of tableting into tablets.
