Tablet Press Machine

Single-pressure Automatic Rotary Continuous Tablet Press Machine

Name: Single-pressure Automatic Rotary Continuous Tablet Press Machine
Brand: SED-pharma

Single-pressure Automatic Rotary Continuous Tablet Press Machine Product Description of Rotary Tablet Press Machine SED-330-17Y-B Automatic Rotary Tablet Press is a single-pressure automatic rotary continuous tablet press developed by our factory. It can press granular raw materials into various ordinary and special-shaped tablets. It is mainly suitable for electronics, food, daily necessities, pharmaceuticals and other industrial sectors. The outer shell is fully enclosed, and the material is made of stainless steel, which meets the GMP standard. Equipped with a trans

Single-pressure Automatic Rotary Continuous Tablet Press Machine, view 1

Single-pressure Automatic Rotary Continuous Tablet Press Machine, view 2

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	SED-pharma
Certification:	CE
Model Number:	SED-330-17Y-B

Payment & Shipping Terms:

Minimum Order Quantity:	>=1 Pieces
Price:	$9,000.00
Packaging Details:	Export standard packing
Delivery Time:	Est. Time(days)-15-To be negotiated
Payment Terms:	T/T,L/C, ,Cash
Supply Ability:	30 Piece/Pieces per Month

Request configuration

Configuration and product details

Technical overview

Name: Single-pressure Automatic Rotary Continuous Tablet Press Machine
Capacity (pcs/h): 35000pcs/h
Max. Tablet Thickness(mm): 6mm
Rotation Speed(rpm): 30 rpm
Warranty: 1 YEAR
Voltage: 220V/380V

Single-pressure Automatic Rotary Continuous Tablet Press Machine

Product Description of Rotary Tablet Press Machine

SED-330-17Y-B Automatic Rotary Tablet Press is a single-pressure automatic rotary continuous tablet press developed by our factory. It can press granular raw materials into various ordinary and special-shaped tablets. It is mainly suitable for electronics, food, daily necessities, pharmaceuticals and other industrial sectors. The outer shell is fully enclosed, and the material is made of stainless steel, which meets the GMP standard. Equipped with a transparent observation window, you can clearly see the working conditions of the machine and can be fully opened, which is easy to see and maintain the inside.

Product Parameters of Rotary Tablet Press Machine

Model	SED-330-17Y-B
Number of Punch Die	17
Capacity	37000 pcs/h
Max. Main Pressure	60KN
Max. Tablet Diameter	20mm
Max. Filling Depth	15mm
Max. Tablet Thickness	6mm
Turret Speed	37rpm
Motor Power	2.2KW
Weight	1000kg
Overall Dimension	6158901415mm

Feature of Rotary Tablet Press Machine

High pressure, large tablet pressing range, can press ordinary, special-shaped, circular and other shapes of tablets.
Suitable for multi-variety and small-batch production.
Mechanical and electrical integration, all controllers and adjustment devices are assembled on the same side of the body, easy to operate.
Equipped with pressure overload protection device to avoid machine damage.
The transmission mechanism with oil-immersed lubrication is sealed under the body, prolonging the service life and avoiding cross-contamination.

Application of Rotary Tablet Press Machine

Single-pressure Automatic Rotary Continuous Tablet Press Machine product detail
