Tablet Press Machine
High Safety Level Tablet Machine Automatic Rotation Shape-Pressing Equipment
High Safety Level Tablet Machine Automatic Rotation Shape-Pressing Equipment Product Description of Rotary Tablet Press Machine 1.1. The rotary tablet press is a machine with automatic rotation and continuous tablet pressing. It is not only suitable for the research and development of new products in the laboratory, but also as a machine for mass production of enterprises, so it is widely used in the pharmaceutical industry, and is also suitable for the production of tablets in the chemical, food, and electronics industries. (See Fig.1) 1.2. This series of tablet press
| Place of Origin: | China |
|---|---|
| Brand Name: | SED Pharma |
| Certification: | CE |
| Model Number: | SED-226-8Y-B |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 50-60 Days after receiving the deposit |
| Payment Terms: | T/T,L/C, ,Cash |
| Supply Ability: | 30 Sets per month |
Configuration and product details
Technical overview- Name
- High Safety Level Tablet Machine Automatic Rotation Shape-Pressing Equipment
- Max.Main Pressure(kn)
- 80
- Max.Pre-pressure(kn)
- 10
- Max.Dia of Tablet(mm)
- 22
- Overall Size (mm)
- 750×660×1620
- Motor Power (kw)
- 2.2kw
- material
- stainless steel
- key word
- Tablet Press Machine
High Safety Level Tablet Machine Automatic Rotation Shape-Pressing Equipment
Product Description of Rotary Tablet Press Machine
1.1. The rotary tablet press is a machine with automatic rotation and continuous tablet pressing. It is not only suitable for the research and development of new products in the laboratory, but also as a machine for mass production of enterprises, so it is widely used in the pharmaceutical industry, and is also suitable for the production of tablets in the chemical, food, and electronics industries. (See Fig.1)
1.2. This series of tablet presses are suitable for the compression of granular raw materials that can be compressed (within the pressure range of the machine) and whose powder content (above 100 mesh) does not exceed 10%.
1.3. This series of tablet presses are suitable for pressing round, special-shaped and lettering tablets with a diameter of not more than 23 mm.
1.4. This series of tablet presses are not suitable for the compression of semi-solid, moist particles, low-melting point and moisture-prone raw materials and powder without particles.
Product Parameters of Rotary Tablet Press Machine
| Model | SED-226-8Y-B |
| Dies (sets) | 8 |
| Type of Tooling | 1′D |
| Max. Pressure (kn) | 80 |
| Max. Pre-Pressure(kn) | 10 |
| Max. Tablet Diameter (mm) | 22 |
| Max. Filling Depth (mm) | 17 |
| Max. Thickness of largest tablet (mm) | 6 |
| Max. Turret Speed(r/min) | 5-30 |
| Capacity (pcs/hour) | 14400 |
| Motor Power (kw) | 2.2 |
| Overall dimensions (mm) | 750×660×1620 |
| Net weigh t(kg) | 780 |
Feature of Rotary Tablet Press Machine
1. Single-press type, fully enclosed structure, Meet GMP requirement
2. Equipped with pre-pressure and main-pressure structure
3. Main shaft drive, frequency control
4. Advanced turbine retard
5. The turntable is equipped with thrust shaft , self-lubricating shaft
Product Parameters of Rotary Tablet Press Machine
Application of Rotary Tablet Press Machine
Mainly used in the pharmaceutical industry, but also in chemical, food, electronics, plastics, metallurgy and other industries.
