Full Automatic Pharmaceutical Machinery Equipment Pre Made Pouch Packing Machinery



Product Overview of Packing Machinery​



The machine is suitable for a variety of prefabricated bags that require high precision and fragile bulk objects, such as: puffed food, pots, jelly, candy, pistachio, peanuts, dried fruits, dumplings, dumplings, herbs, vegetables, fruits.



Product Parameters of Packing Machinery

Station	1	2
Packing speed	12-18 bags/min	15-36 bags/min
Packing volume	150-2500ml
Bag size	L: 150-400mm, W: 130-300mm
Packing type	Pillow type bag, stand up bag, 3 sides seal bag, 4 sides seal bag
Thickness of film roll	0.04-0.12mm
Air consumption	0.7Mpa, 0.5m³/min	0.75Mpa, 0.7m³/min
Main machine power	1.2 KW	2.5 KW
Power supply	1Ph. 220V, 50/60Hz	1Ph. 220V, 50/60Hz
Net weight	150kg	300kg
Machine dimension	L1680 × W510 × H1500mm	L1680 × W970 × H1500mm



Feature of Packing Machinery​



1. PLC servo and pneumatic control system, large touch screen forms the core of drive control; high reliability and the intellectualized degree, and equipped with safety protection.



2. Adopts high-precision servo vacuum film transport system, more stable, with automatic positioning and tracking system, high positioning accuracy.



3. This machine can be installed with different filling system, so that work for different product, such as linear weigher, multi heads electronic weigher, auger filler, piston filler, etc.



Application of Packing Machinery



Suitable for peanuts, peanuts, snacks, chocolate, nuts, seeds, potato chips, peanuts, pet food, dried fruit, frozen dumplings, biscuits, corn, hardware, plastic and other particles.
