Dual-Frequency Speed Pillow Type Full Automatic Packing Machine



Product Description of Packing Machine​



Can be applied to:Food (Snack bar,Bread,Cookies,IceLolly,Cake.Chocolate,) Plastic(Cutlery,Tray,) hardware(Handle,Bearing,Car parts, Washer, ) Soap,Sponge,Tissue,Card..... etc



1.Drive system is concise, running is more reliable, and the maintenance is more convenient.



2.Because of having a function of the fault self-diagnosis, the fault will be showed in the screen at a glance.



3.Servo control, end-sealing, mid-sealing, filling production is controlled separately.



4.It’s two method , select fixed length mode and induction bag length mode.



5.High sensitivity empty bag sensor, tracking production turn on and off.



6.Bag length setting is more efficiency, easy to linked with production line.



Product Parameters of Packing Machine

Film width	Max.250/320/350/400/450/600/680mm
Bag length	30-900 mm
Bag width	30-250mm
Proudut height	Max.80mm
Film roll diameter	Max.320mm
Pakaging rate	30-230bag/min
Power	220v 50/60Hz 2.4KW
Machine size	(L)3770*(W)670*(H)1450mm
Machine weight	About 700KG
Remarks	Optional Air filling device



Advantages of Packing Machine​



1.Dual-frequency,step drive and servo control systems to be chosen from.Bag length can be set andcuttedimmediately,without regulate empty running.One step adjustment can save time and film.



2.Man-machine interface.convenient parameter setting.



3.Fault self-diagnose function.clear failure display.



4.Sensitive photoelectric eye color tracing and digital input for cut position of sealing make it more accurate location of seal cutting.



5.Independent PID control of temperature make it better suiting to a variety of packaging materials.



6.Positioning shutdown without knife sticking and do not waste packing film.



7.Simple transmission system achieve more reliable work and more convenient.Maintenance.



8.All functions are controlled by software.It is convenient for function adjusting and technical upgrading so that the machine will never drop behind.



9.PLC control system and touch-screen interface can be selected according to your special requirements.
