Vacuum Microwave Fruit Vegetable Drying Machine

Product Description of Vacuum Drying Machine



This machine is suitable for low temperature dry of thermal sensitive materials, especially for sold Chinese medicine, honey, bee products, etc.



Adjustable vacuum is with this equipment and get high dry speed, it can advance more for product quality and get features of equal heating, easily control and convenient installation, etc.



It is widely used in heating sterilizing, ripped of medicine, biology product and forming products. It has special excellent efficient for several kinds of pellet, granule drying.,



As same, this microwave vacuum dryer comes sterilizing function and has features of adjustable power, intelligent control. Safety and sanitation product will be produced by it with long storage period.



Product Parameters of Vacuum Drying Machine

Item	Specification
Model	HWZ-30
Power Supply	380V 50hz Three phase (also can be required by customer)
Working Frequency	2450±50MHZ
Electronic Consumption	44kw
Micro Wave Power	30KW
Motor power	2.2kw
Evaporation Speed	24-30Kg/Hour
Vacuum Rate	-0.075MPa
Micro Wave Leakage	Up to National Standard ≤5MW/CM2
Machine Size	2500×2100×2050mm
Vacuum pump power	11KW
Temperature Range	30-80℃
Packaging Details	Wrapped by stretch Film with desiccant bags Packed in to Export Standard Anti moisture Wooden case Glued Marks label on wooden case



Advantages of Vacuum Drying Machine ​



1.High Efficiency: This processing speed is four times higher than normal drying processing.

2.Uniform Heating: The machine is Micro Wave for heating, So the inner and outer of the raw material will be heated at same time. Then the heating and drying will be very uniform.

3.Easily Controlling: Because of the Micro Wave Heating, so the machine can work continuously. And the power of Micro Wave is easy adjusting without any inertia, so the processing is easy operation and easily controlling. All of the data for Micro Wave can be set by Touch screen.

4.Sterilizing: Micro wave equipments always get functions of sterilizing, fats heating and clean. So the finished products are higher quality with long storage time.

5.The machine comes with Camera for production monitoring.
