Liquid Filling Machine
Automatic Cigarette Oil Eye Drops Filling Machine 50bpm Outlet Speed
Automatic Cigarette Oil Eye Drops Filling Machine 50bpm Outlet Speed Machine Parameters of Eye Drops Filling Machine Kind of bottle Various kind, e.g. round, flat, oval Bottle size* Min. Ø 20mm Max. Ø30mm Speed 40~50bpm Filling volume* 2~10ml Filling accuracy ±0.1ml@3ml Power* 220V 50/60Hz 1.5kw Compress air require 100L/min, 4~6bar Machine size mm Length 2500, width 1200, height 1500 Machine weight: 700kgs Product Description of Eye Drops Filling Machine Eyedrop filling, plugging &capping machine for the application of round eyedrop bottle or similar ones, auto acco
| Place of Origin: | China |
|---|---|
| Brand Name: | SED Pharma |
| Certification: | CE |
| Model Number: | SED-2/1/1GSX |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 50-60 Days after receiving the deposit |
| Payment Terms: | T/T,L/C, ,Cash |
| Supply Ability: | 30 Sets per month |
Configuration and product details
Technical overview- Name
- Automatic Cigarette Oil Eye Drops Filling Machine 50bpm Outlet Speed
- Speed
- 40~50bpm
- Filling volume*
- 2~10ml
- Filling accuracy
- ±0.1ml@3ml
- Power*
- 220V 50/60Hz 1.5kw
- Compress air require
- 100L/min, 4~6bar
- Machine size mm
- Length 2500, width 1200, height 1500
- Warranty:
- 1 Year
Automatic Cigarette Oil Eye Drops Filling Machine 50bpm Outlet Speed
Machine Parameters of Eye Drops Filling Machine
|
Kind of bottle
|
Various kind, e.g. round, flat, oval
|
|
Bottle size*
|
Min. Ø 20mm Max. Ø30mm
|
|
Speed
|
40~50bpm
|
|
Filling volume*
|
2~10ml
|
|
Filling accuracy
|
±0.1ml@3ml
|
|
Power*
|
220V 50/60Hz 1.5kw
|
|
Compress air require
|
100L/min, 4~6bar
|
|
Machine size mm
|
Length 2500, width 1200, height 1500
|
|
Machine weight:
|
700kgs
|
Product Description of Eye Drops Filling Machine
Eyedrop filling, plugging &capping machine for the application of round eyedrop bottle or similar ones, auto accomplish product filling, plug place, cap place, cap screw-on. The machine is composed by a conveyor, ceramic piston pump(alternative peristaltic pump) &fill nozzles, plug &cap sorter, Plug &cap placer, cap screw-on system.
The bottle loading/unloading is done manually, through loading/unloading turntable Ø620mm, or directly from an production line. It is designed and made accordance to GMP regulation.
Feature of Eye Drops Filling Machine
1. This series of automatic powder filling machines are especially designed for various glass vials or antibiotics bottles powder packaging with auto filling, stoppering & capping, widely uses as sterile powder filling, cosmetic mask powder filling, oral powder, greatly welcome in foodstuff, biological products and pharmaceutical & cosmetics fields.
2. With servo motor drive & high-precision screw filling, filling speed & precision is high.
3. PLC system to control, easy to adjust different dosages & speed, easy to operate & maintain.
4. Speed control is frequency conversion, with auto counting, highlu auomatation.
5. Optional acrylic glass protection hood and 100-class laminar flow
Products Show of Eye Drops Filling Machine
Application of Eye Drops Filling Machine
