Capsule Counting Machine
Automatic 16 Passageway Capsule Counting Machine 40-60 Bottles/Min
This counting machine is designed for accurately counting capsules, soft gels, tablets, chewing gum, round pills, and other solid materials.
Product Details:
Payment & Shipping Terms:
Request configuration
| Place of Origin: | China |
|---|---|
| Brand Name: | SED Pharma |
| Certification: | CE |
| Model Number: | SED-16S |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 35 days after receiving the deposit |
| Payment Terms: | T/T,L/C,,Cash |
| Supply Ability: | 30 Sets Per Month |
Configuration and product details
Technical overview- Name
- Automatic 16 Passageway Soft Capsule Counting Machine Convenient Maintenance
- Applicable bottle shape
- 10-500ml round,square plastic bottle
- Production capacity
- 40~60 bottles per minute(It depends on the bottle size,filling quantity and the tablet size)
- The setting range of bottling volume
- 2-9999
- Power supply
- AC220V 50Hz 0.6kw
- Accuracy rate
- >99.5%(better than the industrial standard )
- Air Source
- 0.6 Mpa
- material
- stainless steel
- key word
- Capsule Counting Machine Tablet bottling machine
Automatic 16 Passageway Tablet Gummy Pill Counter Small Capsule Packing Counting Machine
Product Description
This counting machine is designed for accurately counting capsules, soft gels, tablets, chewing gum, round pills, and other solid materials. The contact parts are made of superior 304 stainless steel, meeting GMP requirements. The bottle blocking device on the conveyor belt positions bottles for filling, while material is fed through vibration and counted by photoelectric sensors before being loaded into bottles.
Technical Parameters
| Model Name | SED-16S |
|---|---|
| Application |
|
| Hopper Volume | 70L |
| Capacity | 10-70 bottles/min |
| Filling Quantity | 2-9999pcs/bottle (adjustable) |
| Bottle Size | Diameter ≤50mm, Height ≤180mm |
| Conveyor Belt Width | 114mm |
| Compressed Air | 0.6Mpa, 3.8L/min |
| Voltage | 220V, 50HZ Single Phase |
| Power | 0.9KW |
| Weight | 480kg |
| Overall Dimension (L*W*H) | 1560*1530*1700mm |
Key Features
- 3-stage adjustable vibrating platform for precise speed control of capsule count output
- Strong compatibility with tablets (including special-shaped), capsules, soft capsules, and pills
- 16-channel vibration discharge system for smooth, damage-free material handling
- Anti-dust photoelectric sensor technology for stable operation in high dust conditions
- High accuracy counting with photoelectric sensor technology
- Intelligent operation with multiple detection alarm control functions
- Automatic detection for tilted bottles and bottle jams
- User-friendly touch screen interface
- No mold changes required when switching counting objects
Machine Display
Applications
This machine is designed for counting and packing solid particles including tablets, capsules (transparent or non-transparent hard capsules, soft capsules), and pills (3-20mm wide) into bottles, boxes, and bags. It meets GMP requirements and is suitable for research institutions, hospitals, small and medium-sized enterprises, and healthcare product plants.
