360° High Speed Automatic Capsule Appearance Inspection Machine GMP Compliant



Product Overview of 360° High-Speed Automatic Capsule Appearance Inspection Machine

The SED-JSJT-E series 360° High-Speed ​​Automatic Capsule Appearance Inspection Machine is a high-precision, fully automated capsule defect detection system designed specifically for the pharmaceutical industry.



This equipment utilizes advanced imaging technology to achieve a 360° scan of the capsule surface without blind spots, effectively identifying minute defects that affect product quality.



Product Parameters of 360° High-Speed Automatic Capsule Appearance Inspection Machine

Model	SED-12-1440JSJT-E	SED-30-3600JSJT-E	SED-60-7200JSJT-E
Channel	12 channel	30 channel	60 channel
Detection Speed	86,400 pcs/hour	216,000 pcs/hour	432,000 pcs/hour
Applicable	00#~5#, dosage forms other than standard specifications shall be subject to the test results
Inspection Item	Stains, scratches, foreign object attachments, punctures, dents, anomalies, discoloration, etc
Detection Range	360 degree all-round
Accuracy	0.05 MM, Adjustable accuracy
Operation Screen	Touch screen (18.5 inches)
Power Supply	380 V ; 50Hz
Power	3 KW	3 KW	4 KW
Environment	Temperature: 10-30°C; Humidity: 30-70%
Size	9259501400 MM	11109501400 MM	126310901400 MM
Weight	500 KG	600 KG	900 KG



Feature of 360° High-Speed Automatic Capsule Appearance Inspection Machine

• 360° All-Around Inspection: Completely eliminates blind spots, covering the entire surface of the capsule cap, body, and junctions.



• Compatible with All Models: Compatible with standard capsules from 00# to 5# (supports custom testing).



• AI Intelligent Recognition: Efficiently detects stains, scratches, foreign objects, holes, dents, color abnormalities, etc.



• Touchscreen Control: Equipped with an 18.5-inch extra-large touchscreen for real-time monitoring of test data and intuitive operation.



• Precision Control: Accuracy up to 0.05 mm, meeting extremely stringent GMP pharmaceutical standards.

Show of 360° High-Speed Automatic Capsule Appearance Inspection Machine
