Pharmaceutical Machinery Equipment

Rice Wheat Turmeric Pulverizing Grinding Machine

Name: Rice Wheat Turmeric Pulverizing Grinding Machine
Brand: SED

Product Parameters of Grinding Machine Type SED-18FS-B Production capacity (kg/h) 10-30 Main-shaft speed (r/min) 5800 feeding granularity (mm) 10 Smash fineness(mesh) 20-120 Smash motor(kw) 2.2 Outline dimension L×W×H (mm) 500×600×1100 Main Purpose: This device is a new generation of grinder equipment suitable for pharmacy, chemical, food, etc. Principle This device makes use of the relative motion of moved fluted disc and fixed fluted disc to grind materials by the impact and friction of cogs and the materials impact on each other. The grinded materials will enter into c

Product Details:

Place of Origin:	China
Brand Name:	SED
Certification:	CE
Model Number:	SED-18FS-B

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Wooden Case
Delivery Time:	40 Working days after receiving advanced payment or original L/C
Payment Terms:	T/T,L/C, ,Cash

Request configuration

Configuration and product details

Technical overview

Name: Rice Wheat Turmeric Pulverizing Grinding Machine
Model: SED-18FS-B
Production capacity (kg/h): 10-30
Main-shaft speed (r/min): 5800
Smash fineness(mesh): 20-120
Smash motor(kw): 2.2
Outline dimension L×W×H (mm): 500×600×1100
key word: Pulverizing Grinding Machine

Product Parameters of Grinding Machine

Type	SED-18FS-B
Production capacity (kg/h)	10-30
Main-shaft speed (r/min)	5800
feeding granularity (mm)	10
Smash fineness(mesh)	20-120
Smash motor(kw)	2.2
Outline dimension L×W×H (mm)	500×600×1100

Main Purpose:

This device is a new generation of grinder equipment suitable for pharmacy, chemical, food, etc.

Principle

This device makes use of the relative motion of moved fluted disc and fixed fluted disc to grind materials by the impact and friction of cogs and the materials impact on each other. The grinded materials will enter into collector automatically by the action of rotating centrifugal force; and the dust will be filtered and discharged by cloth-bag. This device is designed with the “GMP” standard and is made of stainless steel.

Feature
