Mini Type Tablets Sugar Coating Machine As Pharmaceutical Machinery Equipment

Mini Type Tablets Sugar Coating Machine As Pharmaceutical Machinery Equipment



Product Overview of Coating Machine​



Our this small chocolate coating machine is mainly used for coating the nuts, peanuts ects. It is the last processing step to make ball type products.

The speed can be adjusted and the hot air blower will be equipped on the small chocolate coating machine. The coating bowl is made of stainless steel and the frame is made of normal steel with painting.



Product Parameters of Coating Machine​

Model	SED-JB300	SED-JB400	SED-JB600	SED-JB800	SED-JB1000
Dia. of Pan ( mm)	300	400	600	800	1000
Rotary Speed of Pan ( r/min)	46	46	46	36	32
Power of Fan( kw)	0.075	0.075	0.075	0.12	0.12
Power of Heat kw	0.75	0.75	1	2	2
Production Capacity( kg/time)	2	5	15	36-50	45-70
Motor( kw)	0.37	0.55	0.75	1.1	1.1
Overall Size ( mm)	520*360*700	540*400*800	930*800*1000	1000*800*1480	1070*1000*1580
Net Weight( kg)	46	52	120	205	230



Use of Coating Machine



This small chocolate coating machine consists of main body, worm wheel box, coating pan, heating device, hot air & common blower, electrical equipment, etc.
The transmission process that the motor drives the worm wheel and worm via triangle belt to make the coating pan rotate. Then the material revolves up and down in the coating pan, so that even mixing, pelletizing and polishing can be completed well.



Feature of Coating Machine​



1,This machine is a special equipment which is used to coat the flour



or sugar and to form the shape.



2,The coated peanuts are round and smooth.



3,It also can process almond, cashews, soybeans and so on.



4,This equipment has been up to the export processing standard.



Show of Coating Machine



Application of Coating Machine



This machine is mainly used for the production of tablet granules and film coating. It can also be used to make spherical products or granules, mixing, polishing, etc. Such as: chocolate polishing, peanut coating, sugar coating, seasoning, production of tapioca pearls, desiccant and aluminum hydroxide granulation, porcelain ball making, etc.
