Product Details:
|
| Name: | High Speed Full Automatic Labeling Machine | Production Capacity: | 2000-9000 Bottles/hour |
|---|---|---|---|
| Input Power: | 1.3kw | Input Voltage: | 220V AC |
| Weight: | 480kg | Applicable Diameter Of Bottle Body: | Φ28 Mm-Φ100 Mm |
| Material: | Stainless Steel | Key Word: | Sticker Labeling Machine |
| Highlight: | automatic labeling equipment,sticker labeler machine |
||
Product Description of Sticker Labeling Machine
Shrink label sleeving machine adopts PLC programmable controller, imported servo motor, servo driver, frequency converter and transducer; besides, it adopts the positioning module to ensure the casting.label precise,rapid and stable. It not only has a highly precise position for casting label, but also can withstand the perfect shape of the bottle after shrinkage.
1. The new bottle label steam shrinking furnace has greatly improved heat shrinkage efficiency and is suitable for various plastics and glass bottles. For different bottle types and irregular round bottles, square bottles, flat bottles, etc., the furnace is easy to adjust and maintain. Shrinkage is flat.
2. The steam injection method adopts the design of steam distribution package, adjustable steam guiding system, the pipeline is smooth and does not occupy space, and the discharge outlet is divided into three sections on each side. The height of each section, front and rear and air volume can be adjusted separately to reach the maximum. Good shrinkage effect.
3. The low-pressure steam distribution bag is designed with seamless steel pipe, and each connecting pipe uses a stainless steel hose quick connector, which is convenient for disassembly and installation.
4. The whole machine casing is made of stainless steel SUS304, which saves energy and meets food safety standards.
5. The bottom stainless steel water tray is concentrated with condensed water, which can be taken out and the working environment is not affected.
Product Parameters of Sticker Labeling Machine
| Main performance parameter: | |
| Production capacity : | 2000-9000 bottles/hour |
| Input power : | 1.3kw |
| Input voltage : | 220V AC |
| Size of host machine (L*W*H) : | 2000*850*1900mm |
| Weight : | 480kg |
| Applicable diameter of bottle body : | Φ28 mm-Φ100 mm |
| plicable length of label : | 30 mm-220 mm |
| Applicable thickness of label: | 0.03 mm-0.13 mm |
| Applicable internal diameter of paper tube : | 5" - 10 "free adjustment |
Feature of Sticker Labeling Machine
1. All-cover type stainless steel host machine:the whole machine is waterproof as well as rustproof.
2. Adjustable cutter head:uniquely cyclotron cut-off, double sided cutting edge with a long service life.
3. Single positioning center guide pillar:a more stable for label delivery.
4. Synchronous bottle divider: a more stable transmission for bottle.
5. Bottom set of label brush:a more precision for casting label.
6. Label-controlling electric-eye shelf:unique combination of tail and electric-eye to improve the precision
for cutting off the membrane materials.
7. Push-button control cabinet:a more humanized operation.
8. Independent feeding material shelf: the position of the material shelf is optional at will.
Application of Sticker Labeling Machine
