Product Details:
|
| Name: | Semi Automatic Cartoning Machine Multifunctional Vertical Box Filling Machine | Weight: | 450Kg |
|---|---|---|---|
| Production Speed:: | 20-50 Box Per Min | Paper Box's Largest Size: | 200 X 80x 80mm (can Be Customized) |
| Paper Box's Smallest Size: | 60 X 20 X 20 Mm (Can Be Customized) | Paper Quality Of Carton: | 250-350g/m3 |
| Machine Measurement:: | L 1100 X W 1500 X H 1700 Mm | Power: | 0.75kw |
| Key Word: | Semi Automatic Cartoning Machine , BoxCartoning Machine | ||
| Highlight: | Semi Automatic Cartoning Machine,Multi Size Automatic Cartoning Machine,50 Box Automatic Cartoning Machine |
||
Semi Automatic Cartoning Machine Multifunctional Vertical Box Filling Machine
Technical Data of Automatic Cartoning Machine
|
Production speed: |
20-50 box per min |
|
Paper box's largest size |
200 x 80x 80mm (can be customized) |
|
Paper box's smallest size |
60 x 20 x 20 mm (Can be customized) |
|
Paper quality of carton |
250-350g/m3 |
|
Motor horsepower |
1.5KW/H |
|
Power supply |
220V 50/60HZ single phase |
|
Compress air consumption |
260L/min |
|
Machine measurement: |
L 1100 x W 1500 x H 1700 mm |
|
Machine weight |
450Kg |
Features of Automatic Cartoning Machine
(1) It is specially design to pack small quantities multi size box.
(2) With low cost and only require small area. It is suitable for various sizes of box. The machine is a vertical type with multiple function and require a short time to change mould.
(3) 304 stainless steel case
(4) Advanced PLC Control System Combined with 5.7” Colorful Touch Screen Control Panel, can easily set and change the packing parameters.
Show of Cartoning Machine
Application of Cartoning Machine
This product is suitable for packing aluminum plastic blister cards, medicine bottles, cosmetics, poker, electronics and daily necessities.
