Product Details:
|
| Name: | Vacuum Belt Vibrating Vacuum Belt Dryer Pharmaceutical Drying Machine | Temperature Range: | Adjustable Between 20℃-150℃ |
|---|---|---|---|
| Voltage: | 380V,60Hz(China),customized | Power(W): | 10-80kw |
| Weight: | 1.5tons-45tons | Cleaning: | CIP |
| Material: | Stainless Steel | Key Word: | Fluid Bed Dryer Machine |
| Highlight: | 80kw Fluid Bed Dryer Machine,cip fluid bed dryer machine,80kw fluid bed equipment |
||
Product Overview of Vacuum Belt Dryer
Vacuum belt drying equipment is a vacuum drying equipment for continuous loading and unloading.
The drying principle is that the extract to be dried enters the high vacuum dryer through screw pump, and the extract is distributed on multiple tracks through the distribution system.
The motor drive track runs along the direction of the dryer outlet at a set speed.
The material is dried by the independent superhot water heating system and the cooling system.
In the whole drying process, the material is in a high vacuum state, the drying temperature is low and the drying speed is fast.
Retain the active ingredients of the material to the maximum extent possible to obtain a high quality final product.
And the whole process is dry in the closed state, the material life is very high.
Vacuum belt drying technology has a wide range of applications and can be applied to most extracts.
Especially for high viscosity, easy to agglomerate, thermoplastic and thermal sensitive materials, vacuum belt dryer can overcome other drying equipment drying temperature, high operating cost, low yield shortcomings of vacuum belt dryer can be a complete CIP online cleaning.
CIP cleaning of batch to batch, product to product online is very convenient for equipment advantage
Product Parameters of Fluid Bed Dryer
| Type | Vacuum Belt Dryer | Voltage | 380V,60Hz(China),customized |
| Power(W) | 10-80kw | Temperature range | Adjustable between 20℃-150℃ |
| Weight | 1.5tons-45tons | Cleaning | CIP |
Feature of Vacuum Belt Dryer
1. Continuous vacuum loading and unloading can be dried, broken and granulated under vacuum conditions.
2. Realize continuous line automation of drying process. Organic solvent can be recycled, no emissions and pollution.
3. The operating cost of this system is 1/36 of that of vacuum oven and spray drying. Adopting low temperature rapid drying technology will greatly improve product quality.
4. Solved the problem of continuous drying of heat-sensitive, high-sugar and high-viscosity materials
5. The granulation process is completed in a vacuum to avoid moisture absorption, waste and pollution. The whole system adopts PLC automatic control.
6. Realize online CIP automatic cleaning
Show of Fluid Bed Dryer
Application
It is suitable for drying and cooling of powdery and granular materials in chemical, pharmaceutical, food, dehydrated vegetables, grain, mining and other industries.
